18-14 REAR SUSPENSION
• Down the rear brake pedal, remove the pivot shaft.
• Remove the swingarm.
• Remove the chain buffer.
• Remove the plates.
• Remove the following parts from the swingarm.
Spacer

1
Oil seal

2
Washer

3
Thrust bearing

4
Dust seal

5
Spacer

6
