Suzuki RM-Z250 Owner's Service Manual

SERVICING INFORMATION 19-19
Pass through the hot starter cable between frame bridge and flame, then through between radiator and frame, and through outside overflow pipe.
Pass through the clutch cable into the bracket.
Pass through the lead behind the engine mounting plate.
Pass through the throttle cable between frame bridge and frame, then through between radiator and frame, and through under overflow pipe.
2.2 N
.
m
(0.22 kgf-m, 1.60 lb-ft)
1.5 – 2.5 mm (0.06 – 0.10 in)
1.5 – 2.5 mm (0.06 – 0.10 in)
2.2 N
.
m
(0.22 kgf-m, 1.60 lb-ft)
2.2 N
.
m
(0.22 kgf-m, 1.60 lb-ft)
10 – 12 mm (0.39 – 0.47 in)
Approx. 3 mm (0.12 in)
