5-2 ENGINE REMOVAL AND INSTALLATION
ENGINE REMOVAL AND INSTALLATION
REMOVAL
Drain engine oil. (!2-12)
Drain engine coolant. (!13-3)
Remove the seat
1.
Remove the radiator covers
2, left and right.
Remove the right frame cover
3.
Place the jack under the frame to support the motorcycle.
Turn the fuel valve lever to the “OFF” position and disconnect
the fuel hose
4.
Remove the fuel tank with the fuel valve.
" WARNING
To prevent the motorcycle from falling, make sure to
support the frame with a jack.
