OPERATING YOUR VEHICLE

54P00-01E

Automatic brake system

When a frontal crash is unavoidable at lower speeds, the brakes will powerfully operate

automatically. (#1)

54P000321

(#1) After the vehicle has been stopped by the automatic brake system, flashing of the

radar brake support system warning light and frontal collision warning will continue

until the brake system is released.

NOTE:

If you do not depress the clutch pedal when the vehicle has been stopped by the auto-

matic brake system, the engine will stall.
