Suzuki VITARA series Owner's Manual

7-52
INSPECTION AND MAINTENANCE
54P00-01E
Reversing light
54P000723
1) Open the tailgate. Remove 15 clips (1),
and then pull out the trim (2).
54P000724
2) Disconnect the coupler (3) by pushing
the lock release. Turn the bulb holder of
the reversing light (4) counterclockwise
and remove it.
61MM0B090
(5) Removal
(6) Installation
3) To remove and install the bulb of the
reversing light (4), simply pull out or
push in the bulb.
License plate light
61MM0B086
1) Turn the cover (1) counterclockwise to
remove it.
(1)
(2)
(3)
(4)
(4)
(5)
(6)
EXAMPLE
(1)
