Suzuki VITARA series Owner's Manual

7-47
INSPECTION AND MAINTENANCE
54P00-01E
61MM0B078
(3) Removal
(4) Installation
2) To remove the bulb of the front turn sig-
nal light (1) from the bulb holder, push
in the bulb and turn it counterclockwise.
To install a new bulb, push it in and turn
it clockwise.
To remove and install the bulb of the
front position light (2), simply pull out or
push in the bulb.
Front fog light (if equipped)
1) Start the engine. Turn the steering
wheel to the opposite side of the fog
light to be replaced to replace the bulb
easily. Then turn off the engine.
54P000732
2) Remove the screws (1).
54P000712
3) Remove the clips (2) by prying them off
with a flat-bladed screwdriver as shown
in the illustration.
(2)
(1)
(3)
(4)
EXAMPLE
(1)
EXAMPLE
(2)
EXAMPLE
