2-63

BEFORE DRIVING

54P00-01E

Instrument cluster

1. Speedometer

2. Tachometer

3. Fuel gauge

4. Temperature gauge

5. Information display

6. Warning and indicator lights

54P000230

2 16

64 5 36

EXAMPLE
