2-32
BEFORE DRIVING
54P00-01E
61MM0A060
Fastening
Before fastening the rear center lap-shoul-
der belt, check that the detachable con-
nector (1) is securely latched and the
webbing is not twisted.
To fasten the belt, sit up straight and far
back into the seat, pull the latch plate (2)
across your body and press it straight into
the buckle (3) until you hear a click.
61MM0A094
Unfastening
To unfasten the seat belt, push the button
on the buckle (3) and retract the belt slowly
while attaching a hand to the belt or/and
the latch plate.
61MM0A061
61MM0A062
(1)
(2)
(3)
CENTER
(3)
WARNING
To minimize risk of severe injury or
death in the event of a crash, always
fasten seat belt with both latches
buckled.
To Next Page
