7-50

INSPECTION AND MAINTENANCE

54P00-01E

54P000716

5) Disconnect the coupler by pushing the

lock release. Turn the bulb holder coun-

terclockwise and remove it.

Rear combination light

54P000718

1) Remove the bolts (1) and pull the light

housing (2) straight.

54P000719

2) Remove the wire of the rear turn signal

light (3) from a clamp (4).

EXAMPLE

(1)

(2)

(3)

(4)
