5-50

OTHER CONTROLS AND EQUIPMENT

54P00-01E

Listening to the radio (Type A)

84MM00517

(5)

(4)

(2)

(3)

(1)

(6)

EXAMPLE

Display

68LM561

(1) “FM/AM/DAB” (if equipped) button

(2) UP button

(3) DOWN button

(4) “TUNE/FLD PUSH SOUND” knob

(5) PRESET buttons ([1] to [6])

(6) “AS” button

(A) Band

(B) Frequency

(A)

(B)
