5-83

OTHER CONTROLS AND EQUIPMENT

54P00-01E

Anti-theft feature

84MM00526

(1)

(3)

(4)

(2)

(1)

(3)

(4)

(2)

Type A

Type B

EXAMPLE

(1) “VOL PUSH PWR” knob

(2) PRESET buttons ([1] to [6])

(3) UP button

(4) “TUNE/FLD PUSH SOUND” knob
