7-31

INSPECTION AND MAINTENANCE

54P00-01E

We highly recommend you use “SUZUKI

GEAR OIL 75W-85” for transfer oil (4WD)

and rear differential oil (4WD).

Transfer oil (4WD)

Rear differential oil (4WD)

71LMT0701

Gear oil level check

5-speed manual transaxle

52LM021

(1) Oil filler and level plug

6-speed manual transaxle

71LS10701

(2) Oil filler and level plug

Transfer (4WD)

61MM0B065

(3) Oil filler and level plug

Rear differential (4WD)

61MM0B066

(4) Oil filler and level plug

-30

-22

-20

-4

-10

14 32 50 68 86 104

010203040

75W-85

(1)

EXAMPLE

(2)

(3)

EXAMPLE

(4)

EXAMPLE
