5-24

OTHER CONTROLS AND EQUIPMENT

54P00-01E

Air outlet

54P000532

1. Windshield defroster outlet

2. Side defroster outlet

3. Side outlet

4. Center outlet

5. Floor outlet

* if equipped

EXAMPLE

76MH0A118

When each outlet is open, air comes out

regardless of the air flow selector position.
