5-78

OTHER CONTROLS AND EQUIPMENT

54P00-01E

Bluetooth

®

audio (if equipped)

84MM20502

(2)

(1)

(5)

(4)

(3)

(2)

(1)

(5)

(4)

(3)

Type A

Type B

EXAM-

Steering switch

Display

(1) “MEDIA” button

(2) “TUNE/FLD PUSH SOUND” knob

(3) UP button

(4) DOWN button

(5) “DISP” button

(6) Bluetooth

®

setup button

(A) Track number

(B) Play time

(6)

(B)

(A)
