OTHER CONTROLS AND EQUIPMENT

54P00-01E

Interior light

54P000507

(1) Glove box light (if equipped)

(2) Footwell lights (if equipped)

54P000550

(3) Front (without overhead console)

(4) Front (with overhead console)

(5) Center (without sunroof)

(6) Center (with sunroof)

(7) Luggage compartment (if equipped)

NOTICE

If the vanity mirror has a light, do not

leave the mirror cover open for a long

time, or the battery will discharge.
