Takeuchi TB175 User Manual

197
OPTIONS
Overload Warning Device
If a weight greater than the machine is
designed to lift is lifted, the overload warning
device is activated and a horn is sounded
(when the overload warning switch is turned
on).
WARNING
Continuing to apply the load after the
overload warning horn sounds could
result in the machine tipping over or the
emergency shut-off valve being activated.
If the horn sounds, stop operating the
machine and lighten the load.
Overload warning switch (2)
O position .... OFF
I position .... ON When the emergency
shut-off valve is activated, the overload
warning horn stops. (This is because the
pressure sensor can no longer detect
hydraulic pressure.)
Load Safety Device
L3L0061
2
N0L0061
3
4
5
2
4. Tighten the stem (4) secure it with the lock
nut (3).
Tightening torque:
• Stem (4) 1.0 to 1.5 N·m (0.7 to 1.1 ft-lb.)
• Lock nut (3) 3.2 N·m (2.4 ft-lb.)
Type B
If the engine can be started, the boom or
arm can be lowered with the operating lever.
Check for safety, then slowly lower the boom
or arm.
If the engine cannot be started, the boom or
arm can be lowered using the procedure
described below.
1. Check for safety in the working area and
for stability of the machine and lifted load.
2. Remove the cap (3).
3. Loosen the lock nut (4).
4. Tighten the stem (5) to lower the boom or
arm.
5. Check for stability of the hoe attachment
and load.
6. Loosen the stem (5) secure it with the lock
nut (4).

Takeuchi TB175 Specifications

General

Brand	Takeuchi
Model	TB175
Category	Excavators
Language	English
