Takeuchi TB175 User Manual

37
CONTROLS
Names of Components
1. Instrument cluster
2. Starter switch
3. Light switch
4. Horn button
5. Travel speed switch
6. Wiper switch
7. Safety lock lever
8. Slew speed switch
9. Power mode buttons
Throttle buttons
10. Left operating lever
11. Right operating lever
12. Fuse box
13. Boom swing pedal
14. Travel lever
15. Auxiliary hydraulic switches
16. Blade lever
17. Decel. button
18. Fan switch (Heater)
19. Heater / Defroster switch
20. Ventilation/Circulation switch
21. Cigarette lighter
22. Selector Button (2-Piece boom)
23. Pedal lock
24. Intermediate boom operation indicator
lamp (2-Piece boom)
L3B0022
16
24
2
8
21
3
12
9
6
10
15
14
14
17
13
7 5
18
4
11
19
20
23
1
22
