94
TRANSPORT
Cautions on Transporting
WARNING
¡¡
¡¡
¡Know and follow the safety rules,
vehicle code and traffic laws when
transporting the machine.
¡¡
¡¡
¡Consider the length, width, height and
weight of the truck with the machine
loaded on it when determining the best
route.
TRANSPORT
Securing the Machine
After loading the machine in the designated
position, secure it as described below.
Transporting Posture
1. Lower the dozer blade.
2. Fully extend the bucket and arm cylinders,
then lower the boom.
3. Stop the engine and remove the starter
key.
4. Raise the safety lock lever to engage the
lock.
5. Set stoppers in front and behind the
crawlers.
6. Put a chain or wire rope over the lower
frame and fasten it securely to prevent
sideways slippage.
7. Secure the bucket with a chain or wire
rope.
IMPORTANT: Place a wooden block
under the bucket so that it is not damaged
by hitting the floor.
Wire rope
Padding
E4F002
To Next Page
