212
OPTIONS
Air Conditioner
Cleaning the Condenser
CAUTION
Cleaning the condenser with high
pressured water may damage it. Clean the
condenser gently.
If the condenser is dirty, heat will not
discharge properly. Wash dirt off the
condenser with water.
1. Remove the cover (1) on the right side of
the cab.
2. Clean the condenser (2).
Cleaning the Filters
Clean the filters sooner when operating in
dusty places.
If the filters are clogged, the air becomes
weak and a muted booming sound is heard
from the air conditioner unit.
Removing the filters
1. Move the seat all the way forward, then
fold down the seat back toward the front.
2. Loosen the bolts and remove the cover (1).
3. Loosen the knob and remove the filter
stopper (2).
4. Lift the filter (3) upwards and off.
5. Remove the filter (4).
6. Use compressed air or water to clean the
filters, depending on how dirty it is.
Cleaning
CAUTION
Wear safety glasses when using
compressed air.
1. Blow dry, compressed air (138 KPa or 20
psi or less) directly on the filters from the
inside, moving up and down along the
creases.
Be sure to keep the nozzle at an adequate
distance from the filters.
2. For tough dirt, wash the filter (4) with
neutral detergent and water. Dry the filter
(4) completely after washing it.
1
2
L3T011
1
3
2
4
L3T018
To Next Page
