Technical data
Power supply: 210 ... 250V~ 50-60 Hz
Power input: max. 2.8 W
Fuse: 3.15 A fast-acting (device + output)
Supply cable: 3x 1mm² H05VV-F conforming to EN 60730-1
Case: plastic: ABS, flame resistance: Class V0 to UL94 Norm
Protection rating: II – protective insulation
Protection class: IP40
Dimensions (W/H/D): 152x101x48 mm
Weight: 210 g
Allowed ambient temperature: 0 to 45° C
6 inputs: optional for temperature sensor (KTY (2 k), PT1000),
radiation sensor, as digital input,
or as impulse input for volume flow encoder (only input 6)
3 outputs: output A1 ... Triac output (minimum load of 20W required)
output A2 ... relay output
output A3 ... relay output
Rated current load: Output 1: max. 1.5 A ohmic inductive cos phi 0.6
Output 2 and 3: max. 2.5 A ohmic inductive cos phi 0.6
2 control outputs: 0 - 10V / 20mA individually switchable to PWM (10V / 500 Hz),
supply +5 V DC / 10 mA or connection of the auxiliary relay
HIREL-STAG
Cylinder sensor BF: diameter 6 mm incl. 2 m cable
BF KTY – to 90°C continuous load
BF PT1000 – to 90°C continuous load
Collector sensor KF: diameter 6 mm incl. 2 m cable with connection box &
overvoltage protection
KF PT1000 – to 240°C continuous load (momentary to 260°C)
KF KTY – to 160°C continuous load
The sensor lines on the inputs having a cross-section of 0.50 mm² can be extended to
a length of 50 m.
Consumers (e.g.: pumps, valves...) having a cable cross-section of 0.75 mm² can be
connected at a distance of up to 30 m.
Differential temperature: adjustable from 0 to 99°C
Minimum threshold / Maximum threshold: adjustable from -30 to +150°C
Temperature display: PT1000: -50 to 250°C, KTY: -50 to 150°C
Resolution: from -40 to 99.9°C in 0.1°C increments; from 100 to 140°C in 1°C increments
Accuracy: type. +- 0.3%
