65
Stat: Display of the system’s status. Depending on the program selected, various
system statuses are monitored. If any problems have occurred, this menu contains
all of the information.
Par: The navigation keys on the parameter level (, ) allow you to select the icons
under the temperature display and the text line. The parameter selected can now
be released for selection with the down key
(enter). The parameter blinks to
indicate release. Press one of the navigation keys
to change the value by
one increment. Keep the key pressed to keep the value running. The changed
value is adopted when the UP key
(return) is pressed. To prevent unintended
changes in parameters, entry in
Par is only possible using the code 32.
Men: The menu contains basic settings to determine additional functions such as the
sensor type, the system protection functions, function control etc. Use the keys for
navigation and to make changes as usual. The dialogue is only set up via the text
line. As the settings in the menu change the basic features of the control unit,
entry is only possible with a code that only the technician knows.
The settings of the parameters and menu functions ex works can be restored at any
time using the down key (entry) when plugging the unit in. If this occurs, WELOAD will
appear in the display for three seconds.
Changing a value (parameter)
If a value is to be changed, press the arrow key. This value will then blink and can be set to
the desired value with the navigation keys.
Use the arrow key up to save the value.
Value
blinks
Value
blinks
Value
blinks
