C LEAR P ATH -SC U SER M ANUAL R EV . 1.36 11
T
EKNIC , I NC . T EL . (585) 784-7454
3. C ONNECT C LEAR P ATH -SC S YSTEM C OMPONENTS
Before applying power, connect all ClearPath-SC components as
shown in the hookup diagrams later in this section.
Note: Because the Power Hub component is optional, there are two
different versions of the hookup diagram included in this section. Please
refer to the diagram that most closely matches your system.
24 V OLT L OGIC P OWER S UPPLY
The SC Hub, Power Hub, and other optional components require a 24VDC
nominal power supply to operate. In a small ClearPath SC system (4 axes
or fewer) a 50-75 watt logic supply should suffice.
For help estimating how much power (watts) your logic power supply
must be rated for, see the appendix "Logic Power Supply Sizing".
Tip: See Appendix J for instructions on how to make an inexpensive, no-
crimp power cable for your logic supply.
