C LEAR P ATH -SC U SER M ANUAL R EV . 1.36 25
T
EKNIC , I NC . T EL . (585) 784-7454
M EDIUM S YSTEM (S INGLE P ORT , 3 SC4-HUB S )
Motion related
sensors & signals
(connected through
to each motor)
E-stop circuit
24 VDC
Supply
Windows
(Linux)
Power-off Brake
(3
rd
Party)
RS-232USB
Medium system with multiple SC-Hubs connected to one computer port
Active sensors powered through SC-Hub, e.g., proximity, optical, Hall-effect type, etc.
24V Power-off brake shown wired for axis 0
Note: DC bus power
wiring omitted for clarity.
Safety
Controls
Safety
Controls
