C
LEAR
P
ATH
-SC
U
SER
M
ANUAL
R
EV
.
1.36
20
T
EKNIC
,
I
NC
. T
EL
.
(585)
784-7454
temperature of 65 Celsius. This is required as a method to
reduce burns. A tool shall be required to remove any guards
and/or shields.
• ClearPath-SC motors require that a path exist between the
motor chassis and the Protective Earth (PE) connection of the
machine to which it is affixed. (Note: The PE connection is often
satisfied by simply bolting the motor to the machine; however it
is the users responsibility to verify the PE connection.) If an
external grounding wire is required, use the same or larger wire
gauge as used between the DC power supply and ClearPath
Motor.
• Any maintenance or repair guide created by the user shall state
that power shall be removed before the Protective Earth ground
conductor is disconnected. When reconnecting power, the
Protective Earth ground conductor shall be the first wire
reconnected. Main power may be reconnected only after the
Safety Ground connection is secure.
• When the ClearPath-SC motor is mounted in an application
where the shaft end is higher than the electrical connection end
of the motor, the USB connector plug provided by Teknic must
be installed. The USB plug in these installations becomes an
element to prevent the spread of fire per EN 61010-1 section
9.3.2 part c.
G
ENERAL
D
ISCLAIMER
The User is responsible for determining the suitability of products for their different
applications. The User must ensure that Teknic's products are installed and utilized in
accordance with all local, state, federal and private governing bodies and meet all
applicable health and safety standards.
Teknic has made all reasonable efforts to accurately present the information in the
published documentation and shall not be responsible for any incorrect information which
may result from oversights. Due to continuous product improvements, the product
specifications as stated in the documentation are subject to change at any time and
without notice. The User is responsible for consulting a representative of Teknic for
detailed information and to determine any changes of information in the published
documentation.
If Teknic’s products are used in an application that is safety critical, the User must provide
appropriate safety testing of the products, adequate safety devices, guarding, warning
notices and machine-specific training to protect the operator from injury.
