C
LEAR
P
ATH
-SC
U
SER
M
ANUAL
R
EV
.
1.36
38
T
EKNIC
,
I
NC
. T
EL
.
(585)
784-7454
C
ONNECTIONS
:
T
WO
POWER4-HUB
S
75VDC Bus Input/
Passthrough
75VDC Bus Out (x4)
75VDC
(Bus In)
75VDC
(Bus In)
75VDC Bus Input/
Passthrough
75VDC Bus Out (x4)
75VDC
(Bus In)
75VDC
(Bus In)
24VDC
Aux. Supply
IPC-5 75VDC
Bus Supply
AC Source
110/220VAC
75VDC
Bus Out
Power Hub
Two POWER4-HUBs powering 8 ClearPath-SC motors
