C LEAR P ATH -SC U SER M ANUAL R EV . 1.36 26
T
EKNIC , I NC . T EL . (585) 784-7454
L ARGE S YSTEM (M ULTIPLE P ORTS AND SC4-HUB S )
Motion related
sensors & signals
(connected through
to each motor)
E-stop circuit
24 VDC
USB
24 VDC
RS-232
Windows
(Linux)
Power-off brake
(3
rd
Party)
Note: DC bus power
wiring omitted for clarity.
Large system with multiple SC-Hubs connected to two ports
Two area machine with guard lock under software control in one area
24V Power-off brake shown wired for one axis
Mix of mechanical switches and active sensors powered from SC-Hub
Guard interlock
switch and
solenoid lock
Safety
Controls
Safety
Controls
