Speciﬁcations

Table 1-4: Analog output (cont.)

Characteristics Description

Sin(x)/x bandwidth The sin(x)/x bandwidth can be solved for using the following equation:

20 * log (sin(x )/x) = -3

For interleaved waveforms: x = 2π * fout ÷ fsample

For non-interleaved waveforms: x = π * fout ÷ fsample

fsample = sample rate

fout = sin(x)/x bandwidth

AWG70001A ≤ 25 GS/s (non-interleaved): 11.1 GHz * fsample ÷ 25 GS/s

> 25 GS/s (interleaved): 11.1 GHz * fsample ÷ 50 GS/s

AWG70002A 11.1 GHz * fsample ÷ 25 GS/s

Analog bandwidth

Analog bandwidth is measured with the ideal sin(x)/x response curve of the DAC

mathematically removed from the measured data.

AWG70001A 15 GHz at 50 GS/s

AWG70002A 13.5 GHz at 25 GS/s

Rise/fall time When operating in interleaved mode, rising and falling edges are created using two sample

points. As a result, the rise/fall time is dependent on the sample rate.

AWG70001A ≤ 25 GS/s: < 23 ps

at 30 GS/s: < 42 ps

at 40 GS/s: < 32 ps

at 50 GS/s: < 27 ps

AWG70002A

<22ps

Aberrations

<18%

p-p

for the ﬁrst 100 ps following the step transition w ith 100% reference at 1 ns, for an

ambient temperature range of 20 ºC to 30 ºC

Skew between (+) and (-) outputs

<5ps

1–4 AWG70000A Series and AWGSYNC01 Technical Reference
