Specifications
Table 1-17: AC analog output (AWG70001A, Option AC) (cont.)
Characteristics Description
Band Pass
10 G Hz to 14.5 GHz
±3.5dB
13GHzto18GHz
±4.5dB
Harmonic distortion Measured with a balun.
Output Frequency
2nd harmonic
<1 GHz
< –34 dBc
1GHzto4GHz
< –30 dBc
>4 GHz
< –28 dBc
Output Frequency
3rd harmonic
<1 GHz
< –50 dBc
1GHzto4GHz
< –45 dBc
Operating at 50 GS/s
No filter
>4 GHz
< –33 dBc
Amplifier 1 dB compression AWG70001A operating at 50 GS/s
Output Frequency
Value
1GHz
> 25 dBm
No filter
13 GHz
> 22 dBm
Low Pass
1GHz
> 25 dBm
Band Pass (10 to 14.5 GHz) 11 GHz
> 22 dBm
14 GHz
> 22 dBm
Band Pass (13 to 18 GHz)
18 GHz
> 20 dBm
Switching time The time required for the attenuators and amplifiers to settle to the specified output amplitude
after an amplitude change.
20 ms
Table 1-18: Marker output
Characteristics Description
Connector type SMA on front panel
Number of outputs AWG70001A: 2
AWG70002A: 4
Type of output (+) and (–) complementary output
ON/OFF Control Independent control for each marker
Output impedance 50 Ω
Output voltage Independent control for each marker. Output voltage into RLOAD [Ω] to GND is approximately
(2 * RLOAD / (50 + RLOAD) ) times of voltage setting.
Amplitude range
0.5 V
p-p
to 1.4 V
p-p
into 50 Ω
Amplitude resolution 10 mV
Offset range 1.4 V – (amplitude ÷ 2) to –1.4 V + ( amplitude ÷ 2) into 50 Ω
