Tektronix AWG70002A User Manual

Specifications
Table 1-7: SFDR, AWG70002A operating at 8 GS/s
1
(cont.)
Analog channel
output frequency
In band performance
measured across Specification
Adjacent band
performance
measured across Specification
DC – 2.6 GHz DC –2.6 GHz
–55 dBc
DC – 4 GHz
–52 dBc
DC–3.2GHz DC–3.2GHz
–47 dBc
DC – 4 GHz
–47 dBc
1
Measured with a balun, excluding harmonics.
Table 1-8: SFDR, AWG70002A operating at 16 GS/s
1
Analog channel
output frequency
In band performance
measured across Specification
Adjacent band
performance
measured across Specification
100 MHz
DC–1GHz
–80 dBc
DC – 3 GHz
–72 dBc
0 – 500 MHz
DC – 500 MHz
–68 dBc
DC – 1.5 GHz
–66 dBc
DC–1GHz DC–1GHz
–62 dBc
DC – 3 GHz
–63 dBc
DC–2GHz DC–2GHz
–60 dBc
DC – 6 GHz
–58 dBc
DC – 3.5 GHz DC –3.5 GHz
–57 dBc
DC – 8 GHz
–40 dBc
3.5 – 4.5 GHz 3.5 – 4.5 GHz
–42 dBc
DC – 8 GHz
–42 dBc
4.5 – 6.4 GHz 4.5 – 6.4 GHz
–52 dBc
DC – 8 GHz
–42 dBc
1
Measured with a balun, excluding harmonics.
Table 1-9: Phase noise with jitter reduction, AWG70001A operating at 50 GS/s
Analog output frequency
Offset 100 MHz 1 GHz 10 GHz 16 GHz
100 Hz
–116 dBc/Hz –94 dBc/Hz –75 dBc/Hz –70 dBc/Hz
1kHz
–134 dBc/Hz –116 dBc/Hz –95 dBc/Hz –91 dBc/Hz
10 kHz
–136 dBc/Hz –119 dBc/Hz –101 dBc/Hz –96 dBc/Hz
100 kHz
–138 dBc/Hz –118 dBc/Hz –99 dBc/Hz –96 dBc/Hz
1MHz
–150 dBc/Hz –132 dBc/Hz –112 dBc/Hz –108 dBc/Hz
10 MHz
–156 dBc/Hz –157 dBc/Hz –138 dBc/Hz –130 dBc/Hz
Table 1-10: Phase noise with jitter reduction, AWG70001A & AWG70002A operating at 25 GS/s
Analog output frequency
Offset 100 MHz 1 GHz 10 G Hz
100 Hz
–115 dBc/Hz –95 dBc/Hz –76 dBc/Hz
1kHz
–134 dBc/Hz –115 dBc/Hz –86 dBc/Hz
10 kHz
–138 dBc/Hz –121 dBc/Hz –102 dBc/Hz
100 kHz
–138 dBc/Hz –118 dBc/Hz –100 dBc/Hz
1MHz
–150 dBc/Hz –132 dBc/Hz –113 dBc/Hz
10 MHz
–155 dBc/Hz –157 dBc/Hz –138 dBc/Hz
1–8 AWG70000A Series and AWGSYNC01 Technical Reference
