Specifications
Table 1-28: CPU
module and peripheral devices
Characteristics Description
CPU SN B020000 and above: Intel core I7-4700EQ, 4 core, 2.4 GHz, 6M cache
SN B019999 and below: Intel core 2 duo processor
Memory
SN B020000 and above: 16 GB (2 x 8 GB), DDR3-1600 or faster SODIMM
SN B019999 a
nd below: 4 GB (2 x 2 GB), DDR2-800 or faster SODIMM
Hard disk drive
Solid state
, ≥500 GB, removable
USB 2.0 2 ports, fr
ont panel, type A connector. The front USB ports can be enabled/disabled as a group.
4 ports, rear panel, type A connector. The rear USB ports can be enabled/disabled as a group.
LAN
RJ-45 LAN connector supporting 10 base-T, 100 base-T, and Gigabit Ethernet on rear panel
ESATA 1 port on rear panel, 1.5 Gbps. Instrument must be powered down to make connection.
Video ou
tput
1 VGA port on r ear panel
GPIB Available as an optional accessory that connects to the USB Device and USB Host ports
with the TEK-USB-488 GPIB to USB Adapter
The con
trol interface is incorporated into the instrument user interface.
Table 1-29: Display
Characteristics Description
Display area
132 mm X 99 mm (5.2 in X 3.9 i n, 6.5 in diagonal)
Resolution 1024 X 768 pixels
Touch screen Built-in touch screen
Table 1-30: Power supply
Cha
racteristics
Des
cription
So
urce voltage and frequency
Rating voltage 100 V
AC
to 240 V
AC
Frequency range 50 Hz to 60 Hz
P
ower consumption
<
500 W
WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not exceed 10% of
the operating voltage range.
1–18 AWG70000A Series and AWGSYNC01 Technical Reference
