Specifications
Table 1-25: Pattern Jump In connector (cont.)
Characteristics Description
Number of jump destinations
256
Strobe
Polarity Data is clocked in on negative edge
Minimum pulse width 64 ns
Setup and hold Setup: 5 ns
Hold: 5 ns
Latency to analog output
102,125/fclk +20 ns ± 20 ns
The DAC sampling clock frequency is displayed on the clock settings tab when the external
clock output is enabled.
Holdoff time
>18 μs
Strobe hold off is the amount of delay required at the end of a waveform before another strobe
pulse c an be processed.
Table
1-26: Flag out connectors
Characteristics Description
Connector type SMB on rear panel
Number of Outputs AWG70001A: 4
AWG70002A: 8
Output Impedance 50 Ω
Output Amplitude High: 3.3 V into 50 Ω to G ND
Lo
w: 0 V
Maximum Toggle Frequency <11 MHz
It
will track the sequencer step rate
A
nalog to flag delay Repeatability
I
f Waveform Length/240 = integer, then ≤ 200 ps
If Waveform Length/240 = Noninteger, then ≤ 120/sampling clock
Analog to Flag Output delay -291.5/(sample_clock_rate *2) + 9.76ns ± 5 ns
Table 1-27: 10 MHz reference clock output
Characteristics Description
Connector type SMA on rear panel
Output impedance 50 Ω (AC coupled)
Amplitude +4 dBm ±2 dBm
Frequency (warranted)
10 MHz ± (1 ppm + aging). Sine w ave output
Aging
Within ±1 ppm/year
AWG70000A Series and AWGSYNC01 Technical Reference 1–17
