Tektronix AWG70002A User Manual

Brief procedures
Functional test
The purpose of the procedure is to confirm that the instrument functions properly.
The required equipment is listed below.
Table 2-1: Required equipment for the functional test
Item Qty. Minimum requirements Recommended equipment
Oscilloscope
1 ea.
Bandwidth: 4 GHz or higher
4 channels
Tektronix DPO70404C
Function generator 1 ea. 1 kHz, square wave, 5 V
p-p
output
Tektronix A FG3021C
Signal analyzer
(required for Option AC
only)
1 ea.
Bandwidth: 14 GHz or higher Tektronix RSA5126B
Adapter 3 ea
TekConnect oscilloscope input to SMA input Tektronix TCA-SMA
50 Ω SMA cable
3 ea.
DC to 20 GHz
Tensolite 1-3636-465-5236
50 Ω SMA termination
3 ea.
DC to 18 GHz
Tektronix part number 015-1022-01
(one is supplied w ith the AWG70001A,
two with the AWG70002A).
50 Ω BNC cable
1 ea. Male connectors both ends Tektronix part number 012-0057-01
SMA-BNC adapter
3 ea.
SMA female to BNC male connector
Tektronix part number 015-0572-00
Planar Crown RF Input
Connector – 7005A-1 SMA
Female
(required for Option AC
only)
1 ea.
Planar Crown RF Input Connector – Type N
to SMA Female
For use with Tektronix RSA5126B signal
analyzer
Tektronix part number 131-8689-00
Test waveforms
The following table lists the test waveforms that are used for the functional
test. These are included on the instrument hard drive at: C:\Program
Files\Tektronix\AWG70000\Samples\PV.
Table 2-2: Test waveforms
Waveform name Purpose
PV_Square.wfmx For the triggered output functional test
For the analog and marker functional test
Checking the analog and
marker outputs
Required equ ipment Prerequisites
Oscilloscope
Three TCA-SMA adapters
Three 50 Ω SMA cables
Three 50 Ω SMA terminations
None
