Tektronix TDSUSB2 User Manual

Reference Error Codes and Warnings
Inrush Current Check
USB Limits User Configure Limits 80%-
120%
References
Measure-
ments Hot
Plug Attach
Max Min Max
range
Min range
USB
Pass/Fail
VBUS Default
Volts 5.15
5.25 V 4.4 V
N/A N/A YES Chapter 7, 7.22
Inrush Level 100 mA
N/A
80-120 mA
N/A YES Current Draw.pdf
xxx
Droop Test
USB Limits User Configure Limits 80%-
100%
1
References
Measure-
ments
Max Min Max
range
Min range
USB
Pass/Fail
Droop
Compliance
Voltage
<330 mV 70.0 m 264-
396 mV
N/A YES Chapter 7, 7.2.4.1
xxx
1
References Section refers to the chapter numbers in ‘Universal Serial Bus Specifications Revision 2.0-2000’.
Error Codes and Warnings
This section gives a list of error codes that the application displays and their descriptions.
Error Codes
Error Message Description
Possible Solutions
Sequencer Errors
E101
Error importing waveform
from the oscilloscope
The application is trying
to import the waveform(s)
from the selected source(s),
but is not able to import the
waveform to the application
Make sure that the
application settings
are the same as the
selected oscilloscope
channels. Check the
probe connections and
the compliance test fixture
connections for the live
signal(s)
E102
Error in acc essing .tsv file
This error occurs whenever
.tsv file is selected as the
source file and this file is
not a valid .tsv file
Check whether the file
name e xtension is .tsv.
The s elected .tsv source
file may be corrupted. Try
running the application with
a different tsv file
154 TDSUSB2 Universal Serial Bus Measurements Package
