Tenda AC23 User Manual

92
10 IPv6
This router supports IPv4 and IPv6 dual stack protocols. In the IPv6 part, you can:
− Connect to the IPv6 network of ISPs
− Configure the IPv6 tunnel and achieve communications between IPv6 islands
− Change IPv6 LAN settings
10.1 IPv6 WAN settings
10.1.1 Connect to the IPv6 network of ISPs
The router can access the IPv6 network of ISPs through three connection types. Choose the
connection type by referring to the following chart.
Scenario
Connection Type
⚫
The ISP does not provide any PPPoEv6 user name and password.
⚫
The ISP does not provide information about IPv6 address.
⚫
You have a router that can access IPv6 network.
DHCPv6
IPv6 service is included in the PPPoE user name and password.
PPPoEv6
The ISP provides you with a set of information including IPv6 address, subnet mask,
default gateway and DNS server, etc.
Static IPv6 address
Before configuring the IPv6 function, please ensure that you are within the coverage of IPv6 network
and already subscribe the IPv6 internet service. Contact your ISP for any doubt about it.
DHCPv6
DHCPv6 enables the router to obtain IPv6 address from DHCPv6 server to access the internet,
which is applicable in the following scenarios.
− The ISP does not provide any PPPoEv6 user name and password.
− The ISP does not provide information about IPv6 address.
− You have a router that can access IPv6 network.

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
