Tenda AC23 User Manual

168
12.9 Remote management
12.9.1 Overview
Generally, the web UI of the router can only be accessed on devices that are connected to the
router by a LAN port or wireless connection. When you encounter a network fault, you can ask for
remote technical assistance, which improves efficiency and reduces costs and efforts.
To access the configuration page, log in to the web UI of the router, and choose System Settings >
Remote Management.
By default, this function is disabled. When this function is enabled, the page is shown as below.
Parameter description
Parameter
Description
Remote Management
It is used to enable or disable the remote management function of the router.
Remote IP Address
It specifies the IP address of the host which can access the web UI of the router
remotely.
⚫
0.0.0.0: It indicates that hosts with any IP address from the internet can access
the web UI of the router. It is not recommended for security.
⚫
Other specified IP address: Only the host with the specified IP address can access
the web UI of the router remotely. If the host is under a LAN, ensure that the IP
address is the IP address of the gateway of the host (a public IP address).
Port
It specifies the port number of the router which is opened for remote
management. Change it as required.
⚫
The port number from 1 to 1024 has been occupied by familiar services. It is
strongly recommended to enter a port number from 1025 to 65535 to prevent
confliction
⚫
Remote management can be achieved by visiting “http://the WAN IP address of

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
