156
12.3.3 Change the MAC address of the WAN port
If you still cannot access the internet after completing Internet Settings, it could be the result of
the ISPs configuration to bind the internet account information with a fixed MAC address. In this
case, you can clone and change the MAC address of the router to solve the problem.
To access the configuration page, log in to the web UI of the router, and choose System Settings >
WAN Settings.
Default: Keep the factory setting of MAC address.
Clone local MAC address: Set the MAC address of the router to the same as that of
the device which is configuring the router.
Set MAC address: Manually set an MAC address.
Please ensure the cloned MAC address is that of the computer or the router which is already able to
access the internet.
Configuration procedure:
Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in
to the web UI of the router.
Step 2 Choose System Settings > WAN Settings.
Step 3 Click the drop-down box of MAC Address, choose Clone local MAC address, or Set MAC
address and enter the desired MAC address.
Step 4 Click Save.
---End

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda AC23 and is the answer not in the manual?

Tenda AC23 Specifications

General IconGeneral
USB portNo
DC-in jackYes
Connectivity technologyWireless
Ethernet LAN (RJ-45) ports3
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, System, WAN, WLAN, WPS
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2033 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)1733 Mbit/s
VPN supportIPsec, L2TP, PPTP
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Transmit power20/23 dBmW
Antennas quantity7
Antenna gain level (max)6 dBi
Output current1.5 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
CertificationCE/FCC/RoHS
Processor cores2
Processor frequency1000 MHz
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth144.3 mm
Width238.9 mm
Height40.3 mm
