Tenda AC23 User Manual

177
12.12 Automatic Maintenance
Automatic maintenance enables you to make the router restart regularly. It helps improve the
stability and service life of the router.
To access the configuration page, log in to the web UI of the router, and choose System Settings >
Automatic Maintenance.
This function is enabled by default.
Parameter description
Parameter
Description
System Reboot
Schedule
It is used to enable or disable the automatic reboot function.
Reboot At
It specifies the time when the router reboot automatically every day.
Delay
It is used to enable or disable the delay function.
⚫
Ticked: The function is enabled. When the time for rebooting approaches, if there is any
user connected to the router and the traffic over the router's WAN port exceeds 3 KB/s
within 30 minutes, the router will delay rebooting. If there is any user connected to the
router and the traffic over the WAN port does not exceed 3 KB/s within 30 minutes, or
there is no user connected to the router and the traffic over the router's WAN port is
slower than 3 KB/s within 3 minutes, the router will reboot automatically.
⚫
Unticked: The function is disabled. The router enters the sleeping mode during the
sleeping time.
When the system reboot schedule function is enabled, the router detects the traffic over
the WAN port continuously within 2 hours after the specified reboot time and reboot
when the traffic requirement for rebooting is met.

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
