Tenda AC23 User Manual

130
11.6 Filter MAC address
11.6.1 Overview
This function enables you to add devices to the whitelist or blacklist to enable or disable specified
users to access the internet through the router.
To access the configuration page, log in to the web UI of the router, and choose Advanced
Settings > Filter MAC address.
Parameter description
Parameter
Description
MAC Address Filter
Mode
It specifies the MAC address filter mode.
⚫
Blacklist: Wireless devices listed are unable to connect to the WiFi network of the
router, and wired devices listed are unable to access the internet.
⚫
Whitelist: Wireless devices listed are able to connect to the WiFi network of the
router, and wired devices listed are able to access the internet.
Blacklisted Device
It specifies the name or remark for the device.
Whitelisted Device
MAC Address
It specifies the MAC addresses of devices added to the list.
Operation
: It is used to add new devices the blacklist or whitelist.
: It is used to remove devices from the blacklist or whitelist.
Add all online devices
to the whitelist
It is only available when you set the whitelist for the first time. By clicking it, you can
add all currently connected devices to the whitelist.
11.6.2 Only allow specified device to access the internet
Scenario: The Wi-Fi in your home is misused by unknown users sometimes.
Goal: Only allow certain devices of family members to access the internet.
Solution: You can configure the MAC address filter function to reach the goal.

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
