Tenda AC23 User Manual

174
Parameter description
Parameter
Description
2.4 GHz Network
It specifies whether the corresponding WiFi network is enabled or disabled, and the
visibility of the WiFi network.
5 GHz Network
Hotspot Name
It specifies the WiFi name of the respective WiFi network.
Encryption Mode
It specifies the encryption mode of the respective WiFi network.
WiFi Channel
It specifies the channel that the respective WiFi network works in.
WiFi Bandwidth
It specifies the bandwidth of the respective WiFi network.
MAC Address
It specifies the MAC address of the respective WiFi network.
12.10.5 IPv6 status
This part is only displayed when the IPv6 function is enabled. You can view the information of IPv6
connection, including connection type, IPv6 WAN address and IPv6 LAN address.
Parameter description
Parameter
Description
Connection Type
It specifies the IPv6 connection type of the router.
IPv6 WAN Address
It specifies the WAN IPv6 address of the router.
After the IPv6 function is configured, the WAN port of the router obtains a global
unicast IPv6 address or a tunnel address, and a link local address.
Default IPv6 Gateway
It specifies the default IPv6 gateway address of IPv6 network.
Primary IPv6 DNS
It specifies the primary and secondary DNS server address of IPv6 network.

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
