SECTION 4
4-20
1-/ 2-Cylinder
Installation
1. Position recoil starter on powerhead and install mounting bolts.
2. Make sure engine is in NEUTRAL. Install the start-in-gear
protection mechanism
(1)
,
(2)
,
(3)
and
(4)
.
3. Test the operation of the start-in-gear protection mechanism.
WARNING
start-in-gear protection mechanism must be
installed. NEVER return engine to customer with
mechanism disconnected or not functioning
properly.
FLYWHEEL
NOTE
Flywheel magneto must be of a particular strength in
order to run the ignition system. Flywheels seldom
go bad and would only be replaced as a last resort in
solving an ignition problem.
CAUTION
Flywheel is under high torque and requires the
use of special tools for removal and installation.
Failure to use the specified tools can result in
injury or damage to the flywheel or coil plate
electrical components.
19
19
