ELECTRICAL SYSTEM
7-63
1-/ 2-Cylinder
Main Key Switch Test
1. Disconnect terminals
(2)
,
(3)
,
(4)
,
(5)
,
(6)
,
(7)
,
(8)
,
(9)
,
(10)
,
(11)
,
(12)
and
(13)
.
2. Set analog multimeter for continuity. With main key switch
(1)
set
to OFF, ON, START, and PUSH IN positions, check for continuity
between a clean chassis ground and one of these terminals (test
one terminal at a time):
If meter shows continuity in any of these tests, replace main key switch.
3. With main key switch set to the OFF position, check for continuity
between terminals
(4)
and
(6)
. lf meter does not show continuity,
replace main key switch.
Check for continuity between the following terminals, if meter
shows continuity, replace main key switch.
Terminal Terminal Terminal
Terminal Terminal Terminal
Terminal
and
Terminal
and
Terminal
and
Terminal
and
Terminal
and
Terminal
and
T1546
31
31
2 4 6
8 10 12
2 8 2 10 2 12
8 10 8 12 10 12
To Next Page
