TOHATSU 2 Stroke Cylinder Series User Manual

SECTION 7
7-52
1-/ 2-Cylinder
Starter Circuit Tests
These tests are designed to quickly isolate the faulty starter circuit
component if the engine does not crank.
NOTE
The electrical drawings have been simplified to show
only those elements necessary to test the starter
circuit.
Two types of starter circuits are used and illustrated in:
• Models with remote control box.
• Models without remote control box.
T1514A
2
2 3
2
3
