MIDSECTION
5-19
1-/ 2-Cylinder
DRIVESHAFT HOUSING
Removal
1. Remove powerhead as described in Section 4.
2. Remove tiIler steering handle if equipped, this section.
3. Remove lower engine cover, this section.
4. Remove gearcase as described in Section 6.
5. Remove upper rubber mount nut
(1)
.
6. With driveshaft housing tilted fully down, remove the nut
from each lower rubber mount bolt
(2)
. Do not remove the
bolts.
CAUTION
Driveshaft housing is free to fall if lower rubber
mount bolts are removed.
7. Hold driveshaft housing securely and pull lower rubber
mount bolts and remove driveshaft housing. Place housing
on bench for disassembly.
8. Remove the clip from the lower rubber mount and remove
the upper and lower rubber mounts.
NOTE
For the 25/30 and 40 engines, use the special tool
361-72760-0 for removing the rubber mounts.
1
1
2
3
T1669
1
T1671
3
