4.4 HDD 4 Replacement Procedures
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-13
4.4 HDD
Removing the HDD
The following describes the procedure for removing the HDD (See Figure 4-4 to 4-6).
CAUTION: Take care not to press on the top or bottom of a HDD. Pressure may cause
data loss or damage to the device.
1. Turn the computer upside down.
2. Loosen the following screw (with e-ring) and remove the HDD-1 slot cover.
3. Remove the following screw securing the HDD-1 assembly.
• M2.5×6B FLAT BIND screw ×１
4. With the HDD-1 assembly in a vertical position, lift it straight up and away from the
connector CN1850 on the system board.
5. (When an HDD-2 is installed r and removing it,) Loosen the screw (with e-ring)
securing an HDD-2 slot cover and remove an HDD-2 slot cover.
6. Remove the following screw securing the HDD-2 assembly.
• M2.5×6B FLAT BIND screw ×１
7. Disconnect the HDD-2 assembly from the connector CN1860 on the system board by
sliding it toward the arrow pointed.
To Next Page
