1 Hardware Overview 1.8 Batteries
1-22 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
1.8 Batteries
The PC has the following two batteries.
 Main battery
 Real time clock (RTC) battery
Table 1-10 lists the specifications for these two batteries.
Table 1-10 Battery specifications
Battery Name Battery Element Output Voltage Capacity
G71C00063210
G71C00063110
Lithium ion 6 cell 10.8V 4,700mAh
G71C00064210
Main battery
G71C00064110
Lithium ion 9 cell 10.8V 7,050mAh
Real time clock
(RTC) battery
GDM710000041 Nickel hydrogen 2.4V 16mAh
1.8.1 Main Battery
The main battery is the primary power supply for the computer when the AC adapter is not
connected. In Standby, the main battery maintains the current status of the computer.
