Toshiba Qosmio G30 Maintenance Manual

Appendices Appendix C Pin Assignments
C-26 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
C.32 CN6480 1BIT AMP I/F connector (20-pin)
Table C-32 1BIT AMP I/F connector (20-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 1BTMUT-P3N O 2 AMPSD-S3N O
3 NC - 4 A-GND -
5 NC - 6 GND -
7 AVP-PFV - 8 NC -
9 AVP-PFV - 10 NC -
11 AUDP-GND - 12 NC -
13 AUDP-GND - 14 NC -
15 A4R7-P4V - 16 NC -
17 (A4R7-P4V) - 18 EQOUTL-PXP O
19 EQOUTR-PXP O 20 A4R7-P4V -
C.33 CN8800 DC IN connector (4-pin)
Table C-33 DC IN connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (ADPDC) I 2 (ADPDC) I
3 GND - 4 GND -
C.34 CN8810 Battery connector (10-pin)
Table C-34 Battery connector (10-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 PVBL1 O 2 BTMP1 I/O
3 BATDCHG - 4 (M5V) -
5 PSCL-S5P I 6 PSDA-S5P I
7 GND - 8 DBT1DV-S5N I
9 GND - 10 GND -

Toshiba Qosmio G30 Specifications

General

Chipset	Intel 945PM
Operating System	Windows XP Media Center Edition
Optical Drive	HD DVD-ROM drive
Bluetooth	Yes
Battery	6-cell lithium-ion
Processor	Intel Core 2 Duo
RAM	Up to 4GB DDR2 SDRAM (533MHz)
Storage	200GB HDD (5400 rpm)
Display	17.0 inches, 1920 x 1200 pixels
Graphics	NVIDIA GeForce Go 7600
Wireless	Intel PRO/Wireless 3945ABG
Webcam	Integrated 1.3 megapixel webcam
Connectivity	Ethernet, Modem
Ports	USB 2.0, HDMI, VGA
Audio	Harman Kardon speakers
