Toshiba Qosmio G30 Maintenance Manual

Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-19
C.13 CN3200 Keyboard I/F connector (34-pin)
Table C-13 Keyboard I/F connector (34-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 NUMLED-P5N I/O 2
A
RWLED-P5N I/O
3 CAPLED-P5N I/O 4 P5V -
5 KBSC00-S3N O 6 KBSC01-S3N O
7 KBSC02-S3N O 8 KBSC03-S3N O
9 KBSC04-S3N O 10 KBSC05-S3N O
11 KBSC06-S3N O 12 KBRT00-S3N O
13 KBSC07-S3N O 14 KBSC08-S3N O
15 KBSC09-S3N O 16 KBRT01-S3N O
17 KBRT02-S3N O 18 KBRT03-S3N O
19 KBSC10-S3N O 20 KBSC11-S3N O
21 KBRT04-S3N O 22 KBRT05-S3N O
23 KBSC12-S3N O 24 KBSC13-S3N O
25 KBRT06-S3N O 26 KBRT07-S3N O
27 KBSC14-S3N O 28 KBSC15-S3N O
29 P5V - 30 N.C -
31 N.C - 32 N.C -
33 N.C - 34 P5V -
1T GND - 2T GND -
C.14 CN3201 Touch Pad I/F connector (4-pin)
Table C-14 Touch Pad I/F connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 IPDCLK-P5P I/O
3 IPDDAT-P5P I/O 4 P5V -
C.15 CN3330 Volume I/F connector (3-pin)
Table C-15 Volume I/F connector (3-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1
(
ROTEN
A
-S3N
)
O2 GND -
3 (ROTENB-S3N) O
