Appendices Appendix C Pin Assignments

C-30 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)

JK board (FCTJK*)

C.43 CN9551 System board I/F connector (6-pin)

Table C-43 System board I/F connector (6-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 IRBLS1-P5P I

3 GND - 4 GND -

5 IRBLS2-P5P I 6 GND

1T GND - 2T GND -

C.44 J9560 IR bluster 1 connector (5-pin)

Table C-44 IR bluster 1 connector (5-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 NC -

3 NC - 4 NC -

5 IRBLS1-P5P I

C.45 J9561 IR bluster 2 connector (5-pin)

Table C-45 IR bluster 2 connector (5-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 NC -

3 NC - 4 NC -

5 IRBLS2-P5P I
