Appendices Appendix C Pin Assignments
C-20 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
C.16 J4100 Network I/F connector (12-pin)
Table C-16 Network I/F connector (12-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 ZMDIOP-EYP I/O 2 ZMDION-EYN I/O
3 ZMDI1P-EYP I/O 4 ZMDI2P-EYP I/O
5 ZMDI2N-EYP I/O 6 ZMDI1N-EYP I/O
7 ZMDI3P-EYP I/O 8 ZMDI3N-EYP I/O
9 (LAN-E3V) - 10 LLINK-E3N O
11 (LAN-E3V) - 12 LACT-E3N O
1T GND - 2T GND -
C.17 CN4200 1394 I/F connector (4-pin)
Table C-17 1394 I/F connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 ZTPB0-E3N I/O 2 ZTPB0-E3P I/O
3 ZTPA0-E3N I/O 4 ZTPA0-E3P I/O
1T GND - 2T GND -
3T GND - 4T GND -
C.18 CN4400 Bluetooth I/F connector (20-pin)
Table C-18 Bluetooth I/F connector (20-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 BT-P3V - 2 NC -
3 WCHDAT-P3P O 4 ZUSBBT-E3N I/O
5 ZUSBBT-E3P I/O 6 NC -
7 WCHCLK-P3P O 8 (GND) -
9 NC - 10 GND. -
11 NC - 12 NC -
13 BTRST-S3N O 14 NC -
15 NC - 16 NC -
17 NC - 18 BTMDL-P3N I
19 NC - 20 GND -
1T 2T
To Next Page
