Appendices Appendix C Pin Assignments

C-28 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)

C.39 CN9500 LE board I/F connector (20-pin)

Table C-39 LE board I/F connector (20-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 RCIRRX-S5P I

3 BTLED-M5N O 4 LERNLE-S3P O

5 P5V - 6 LERNRX-P5N I

7 LERNON-P5N O 8 FMLED-P5N O

9 BTSWON-S3N O 10 GND -

11 ESTLRD-S5N O 12 SATLED-S5N O

13 BAT1GR-S5N O 14 BAT1OR-S5N O

15 M5V - 16 PWLEGR-S5N O

17 PWLEOR-S5N O 18 DCINGR-S5N O

19 DCINOR-S5N O 20 GND -

1T GND - 2T GND -

C.40 CN9530 FS board I/F connector (6-pin)

Table C-40 FS board I/F connector (6-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 Power P3V - 2 FGSPON-P3V O

3 GND - 4 ZUSBFS-E3N I/O

5 ZUSBFS-E3P I/O 6 GND -

1T GND - 2T GND -

C.41 CN9550 JK board I/F connector (6-pin)

Table C-41 JK board I/F connector (6-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 IRBLS1-P5P O

3 GND - 4 GND -

5 IRBLS2-P5P O 6 GND

1T GND - 2T GND -
